By means of a continuous light band, the object of measurement is scanned all around. An unbroken recording of the measurement points allows an evaluation of the object of measurement without calculation, without interpolation, i.e. your wood is evaluated and shaped according to the actual measured values – no interruption in the conveyor belt, – no mechanic reconstruction. Installing and measuring, scanning at the speed of light, evaluating with high performance processor and evaluating the optimum result. The position of the object of measurement is finally no longer important. The continuous recording of the complete surface allows an optimum measurement of ovality, taper, curvature, sweep, independent of the position of the log and the measuring position. A perfect recognition of cut sections is a matter of course.
Highest accuracy
The new measurement technique allows a certain quality recognition or evaluation resp. Environmental influences, such as temperature fluctuations, pressure differentials and relative humidity are constantly surveyed and compensated. The assembly is very simple and, thanks to the enclosed holding fixture and cables, can also be done by untrained staff. The same applies to the adjustment which is very simple due to an integrated laser point and a test program. Due to scalable measuring ranges, completely new appliances are possible with the JORO-3D.
Features
Measuring
- all-around measuring in one measuring stage
- simplest calibration
- software survey of all sensors
- scalability
Certification
- EU type approval
- CE certification EU
- EMC norms
Mechanics
- no interruption of the conveyor belt
- to a great extent independent of mechanics
- unproblematic installation in existing mechanics
- simple adjustment
Environmental influences
- temperature, pressure, relative humidity are compensated
- extended temperature range without air condition
- waterproof
- dustproof
- stable against vibrations
Standard Industrial Interface
- standard protocols of known producers are available
- configurable data communication
Included Parts
- mechanical fixtures
- cables
- encoder with cable
- installation guide
Applications
- Log yard
- Sorting line
- Sawmill
- Board sorting line
- Log turner
Technical Data
| Scan range | 800mm 1000m |
| Accurancy | <1.5 mm |
| Scan rate | 400 scan/sec |
| Power supply | 230V AC 50Hz |
| Temperature | -20° C ... +50°C |
| Norms |
IP 65, Dustproof, Jet water protectec, IEC 825-1 |
| EMC | CE |
